High-Quality Portable 3D Color Doppler Ultrasound Machine for Hospitals at Affordable Price
SKU: UMY-US-084
Brand: Umy
MOQ: 1
Origin: China
Quick Info.
- SKU NO.: UMY-US-084
- Device Classification: Class Ⅱ
- Warranty: 1 Year
- Power Source: Electric
- Transport Package: Carton
- Origin: China
- Material: Metal, Plastic
- After-Sale Service: Online Technical Support
- Production Capacity: 2600 Sets/Year
This high-quality portable 3D color Doppler ultrasound machine is designed for hospital use, offering advanced imaging capabilities at an affordable price. It provides clear, detailed 3D images for accurate diagnostics in cardiology, obstetrics, gynecology, and musculoskeletal imaging. The machine features a user-friendly interface and is compact enough for easy portability, making it ideal for both routine exams and emergency care. With its high-definition imaging and reliable performance, it is an essential tool for healthcare professionals looking for efficient diagnostic solutions. Perfect for hospitals looking to enhance their imaging capabilities without exceeding budget constraints.
The Specific Parameters
| ITEMS | PARAMETERS |
|---|---|
| Application Scene | Abdomen, gynecology, obstetrics, pediatrics, urology, heart, superficial organs, blood vessels |
| Image Mode and Display | |
| Image Modes | B, B+B, 4B, B+M, CFM, B+CFM, PDI, PDI+B, PW, B-tilt, 3D (Optional) |
| Scanning Modes | Electron convex array, high-frequency linear array, cavity, micro convex, rectum |
| Display | 15-inch LCD screen |
| Gray Level | 256 levels |
| Display Depth | ≥280mm |
| Probe and Frequency | |
| Probe Ports | 2 automatic probe identification ports |
| Frequency Range | 2.0–12.0 MHz |
| Dynamic Range | 80–280 dB adjustable |
| Measurement and Calculation | |
| Scanning Depth | 2–280mm |
| Measurement Modes | B, M, PW, THI |
| Supported Measurements | Distance, circumference, area, volume, angle, heart rate, etc. |
| Departments | Obstetrics, cardiology, urology, general clinical |
| Preset Exam Types | Built-in optimized presets for different exams |
| Image Processing | |
| Gain Adjustment | 8 segments TGC; B/M/D/C gain independently adjustable |
| Pseudo-Color Modes | 16 coding options |
| Optimization Levels | 5 levels: edge enhancement, frame average, gamma, contrast, brightness, etc. |
| Auto Optimization | Yes, with preset image check types |
| Storage and Reporting | |
| Image Storage | Image, video, and movie playback |
| Storage Capacity | ≥128GB SSD |
| Data Management | Medical record storage, patient data, DVD/USB support |
| Report System | Automatic generation with full-screen Chinese/English text |
| Connectivity and Interface | |
| Interfaces | HDMI, VGA, USB, DICOM |
| Input Voltage | 100–240V, 50/60Hz |
| DC Adapter | 19V, 6A |
| Battery Life | ≥1.5 hours (4.5 hours optional) |
| Physical Specifications | |
| Dimensions | 370mm × 382mm × 90mm (L × W × H) |
| Weight | ≤6.5kg |
| Sound Output | Mechanical index, thermal index, sound power adjustable |
