UMHIC002 24-Tube Capillary Blood Centrifuge, 12000 rpm

The UMHIC002 24-Tube Capillary Blood Centrifuge is a compact
benchtop centrifuge designed for hematocrit determination and small-volume blood
sample separation.

With a maximum speed of 12000 rpm and maximum relative centrifugal
force of 14170 × g, the UMHIC002 uses a 24-position capillary rotor
for tubes with a specified volume of 0.25–1 mL.

Key Features

• Maximum speed: 12000 rpm
• Maximum RCF: 14170 × g
• 24-position capillary rotor
• Suitable for 0.25–1 mL capillary tubes
• Digital display for operating parameters
• Brushless DC motor for stable operation
• Low-maintenance motor design
• Speed accuracy: ±10 rpm
• 1–99 minute timer
• Noise level ≤65 dB(A)
• Compact benchtop footprint
• Bottom suction cups for additional operating stability

Typical Applications

The UMHIC002 is primarily designed for capillary blood centrifugation in
laboratory and clinical environments.

Typical applications include:

• Hematocrit value determination
• Capillary blood sample centrifugation
• Small-volume blood separation
• Trace sample separation
• Small hospital laboratories
• Clinical and research laboratories

12000 rpm High-Speed Centrifugation

The UMHIC002 provides a maximum rotational speed of 12000 rpm
and a maximum RCF of 14170 × g.

The high-speed capillary rotor is intended for rapid separation of small-volume
blood samples used in hematocrit and related laboratory procedures.

24-Position Capillary Rotor

The supplied capillary rotor provides capacity for:

• 24 capillary tubes
• Tube volume: 0.25–1 mL
• Maximum rotor speed: 12000 rpm
• Maximum RCF: 14170 × g

The required tube dimensions and compatibility should be confirmed before ordering,
especially when using tubes from different manufacturers.

Brushless DC Motor

UMHIC002 uses a brushless DC motor designed for stable and relatively
quiet operation.

The brushless motor configuration reduces routine motor maintenance requirements
compared with conventional brushed motor systems.

Digital Control and Timer

The centrifuge is equipped with a digital operating display for speed and time settings.

The timer can be adjusted from 1 to 99 minutes, while the specified
speed accuracy is ±10 rpm.

Compact Benchtop Design

With external dimensions of approximately
255 × 310 × 210 mm and a net weight of approximately
5.7 kg, the UMHIC002 is designed for laboratories where bench
space is limited.

Suction cups installed at the bottom of the unit help improve stability during operation.

Technical Specifications

Rotor Parameters

Before Ordering

For configuration confirmation and quotation, please provide:

• Required quantity
• Capillary tube size and volume
• Intended hematocrit or blood separation procedure
• Required operating speed
• Local power supply
• Destination country

Tube dimensions and rotor compatibility should be confirmed before ordering,
especially when using third-party capillary tubes.

Request UMHIC002 Centrifuge Quotation

Contact UMY Medical with your required quantity, tube specification and
delivery country for configuration confirmation and quotation.

Email UMY Medical

WhatsApp UMY Medical

FAQ

What is the maximum speed of the UMHIC002?

The maximum specified speed is 12000 rpm.

What is the maximum RCF?

The maximum specified relative centrifugal force is 14170 × g.

How many capillary tubes can the rotor hold?

The supplied capillary rotor accommodates up to 24 tubes with a specified
volume range of 0.25–1 mL.

What is the timer range?

The timer can be set from 1 to 99 minutes.

What is the main application of this centrifuge?

The UMHIC002 is primarily intended for capillary blood centrifugation,
hematocrit determination and small-volume blood sample separation.
