Veterinary Handheld Pulse Oximeter UMH-100V for Professional Animal Care
The UMH-100V Veterinary Pulse Oximeter is engineered to provide veterinarians and animal care professionals with a low-cost, reliable monitor for spot-checking, continuous monitoring, and recording of functional arterial oxygen saturation (SpO2) and pulse rate. Working with specialized animal sensors, the device supports a variety of species including horses, dogs, and cats weighing from 0 to 200 KG.
Equipped with a 2.8-inch high-resolution color display, three measurement modes (spot-check, record, and monitoring), and 3-level visual and audio alarms, the system ensures patient safety and operational ease.
Supported by extensive data storage for up to 999 patient files (120 hours of trend data), ODMS data management software connectivity, and dual power options (AC charge or 4 AA batteries), the UMH-100V integrates seamlessly into veterinary hospitals and clinical environments.
Key Features
2.8-Inch High-Resolution Display
Features a clear TFT LCD color screen with two display directions and an optimal viewing angle for clinical convenience.
Species-Specific SpO2 Technology
Equipped with high-sensitivity SpO2 technology and specialized veterinary sensors designed specifically for animals (dogs, cats, horses, etc.).
Three Measurement Modes
Offers versatile operation modes including spot-check, record, and continuous monitoring.
Advanced Alarm System
Includes 3-level visual and audio alarms for patient and system status with adjustable alarm ranges (45 to 85 dB).
Extensive Data Storage
Continuously stores up to 120 hours of trend data across 999 patient files with date, time, alarm events, pulse rate, and SpO2 measurements.
ODMS Software & Connectivity
Allows data to be transferred to a computer for comprehensive management, analysis, and printing using the ODMS system.
Technical Specifications
| Technical Parameter | Specification Details |
|---|---|
| Product Model | UMH-100V Veterinary Handheld Pulse Oximeter |
| Display Screen | 2.8-inch TFT LCD color display (240 × 320 pixels) |
| SpO2 Saturation Range & Accuracy | Range: 1% to 100% | Accuracy: 70-100% (±2%), <70% undefined |
| Pulse Rate Range & Accuracy | Range: 25bpm to 350bpm | Accuracy: ±2bpm or ±2% (whichever is greater) |
| Power Supply | 4 AA Alkaline or Ni-Mh batteries (1.5V × 4 or 1.2V × 4) or AC charger |
| Battery Operating Time | Up to 20 hours of continuous monitoring (using 4,800mAh Ni-Mh batteries at 25°C) |
| Data Memory | Saves 120 hours of tabular trend data and 999 patient files |
| Dimensions & Weight | 75mm W × 135mm H × 28mm D | 258g (0.569 lb) including batteries |
- Specifications are based on official technical datasheets for the UMH-100V Veterinary Handheld Pulse Oximeter.
- Standard configuration includes the main handheld unit, standard veterinary SpO2 sensor, and hanging strip.
- Optional accessories include an AC adapter, Ni-Mh/Alkaline batteries, protective cover, and data analysis software.
Applications
Veterinary Clinics & Hospitals
Provides reliable spot-checking and continuous oxygen saturation monitoring during routine clinical examinations.
Surgical & Anesthesia Monitoring
Ensures continuous patient safety tracking during veterinary surgeries and post-operative recovery.
Silent Sleep & Long-Term Care
Supports uninterrupted 24-hour monitoring with silent sleep mode and automatic power-saving features.
System Configuration
The UMH-100V Veterinary Handheld Pulse Oximeter is supplied complete with the main monitoring unit, standard veterinary SpO2 sensor (e.g., lingual clip), hanging strip, and operation manual.
Please confirm your required optional accessories (AC adapter, protective cover, or data analysis software) prior to placing an order.
Before Ordering
- Required order quantity and destination country.
- Optional accessory selection (Protective cover, AC adapter, ODMS data software).
- Species-specific sensor requirements (dogs, cats, horses, etc.).
Request a Veterinary Pulse Oximeter Quote
Contact UMY Medical to discuss system configurations, pricing, and export delivery for your veterinary clinic or distribution business.
Frequently Asked Questions
What animals can be monitored using the UMH-100V?
The oximeter works with specialized veterinary sensors to accommodate various species including horses, dogs, and cats weighing from 0 to 200 KG.
How long can monitoring data be stored?
The unit continuously stores up to 120 hours of trend data and accommodates records for up to 999 patient files.
What power options are available for the device?
It operates on four AA batteries (Alkaline or Ni-Mh) providing up to 20 hours of monitoring, or via an optional AC charger.
Can the recorded data be exported to a computer?
Yes, data can be stored, managed, analyzed, and printed on a PC using the ODMS data analysis software.
