Product name: Veterinary Infusion Pump
Power Source: Electric
Warranty: 1 year
After-sale Service: Online service and delivering spare parts
Transport Package: Carton or Wooden Cases
Material: Metal, Plastic
Instrument Classification: Class Ⅱ
Safety standard: ISO13485
Application: Veterinary Clinic
Power Source: Electric
Warranty: 1 year
After-sale Service: Online service and delivering spare parts
Transport Package: Carton or Wooden Cases
Material: Metal, Plastic
Instrument Classification: Class Ⅱ
Safety standard: ISO13485
Application: Veterinary Clinic
Specific Parameters
| ITEMS | PARAMETERS |
|---|---|
| Parameters Specifications | |
| Accuracy | ≤ ±4.5% (for recommended sets) |
| Mode | Rate mode, Dose Mode, Time mode, Micro-infusion Mode |
| Flow rate | 0.10ml/h – 2000ml/h |
| Increment | 0.1ml/h |
| Preset volume (VTI) | 0.10 – 9999.99ml, increment: 0.1ml |
| Preset time | 00:00:01 – 99:59:59 |
| Accumulated volume | 0.00 – 9999 ml, increment: 0.1ml |
| KVO | 0.1-5ml/h |
| Purge rate | 0.1-2000ml/h |
| Bolus rate | 0.1-2000ml/h (Auto+manual) |
| Occlusion detection | 5 levels selectable: 150mmHg/375mmHg, 600 mmHg/825 mmHg/1125 mmHg |
| Anti-bolus | Unexpected bolus reduced when the occlusion occurs |
| Air bubbles detection | 5 levels selectable: 50/100/250/500/800µL; accumulate air: 0.1-4ml/h |
| History log | ≤1500 events |
| Para. Memory | Previous therapy parameters will be loaded |
| Auto-lock time | 1 – 5 minutes selectable, ON/OFF switchable |
| IV Administration Sets | |
| Compatibility | Universal IV sets |
| Alarms Type | Audible and visual alarm |
| Alarm levels | 2 levels: High (occlusion, air in line, door open, VTI done, KVO finish, battery empty, system error) / Low (battery in use, battery error, system error) |
| Sound volume | 1-8 levels selectable, default is level 4 |
| Reminder | 1-5 minutes selectable, ON/OFF switchable |
| Battery | |
| Operating time | ≥4.5 hours at 25ml/h |
| Charging time | ≤ 5 hours to full capacity |
| Power supply | 100-240V~, frequency 50/60Hz, current 0.3-0.13A |
| Physical Specifications | |
| Weight | ≤ 1.2kg (with normal battery, without pole clamp) |
| Size | 126X200X118mm |
| Screen | 2.2 inch LCD, ≥128×64 pixels |
| Brightness | Fixed |
