Portable HD Video Gastroscope & Colonoscope System for GI Diagnostics
The Portable HD Video Gastroscope & Colonoscope System is engineered to provide clinical practitioners with exceptional mobility and crystal-clear imaging performance for upper and lower gastrointestinal evaluations. Equipped with a high-definition 1,000,000-pixel CMOS image sensor and an integrated portable screen, the system delivers high-contrast visualization directly at the point of care.
Featuring precision-engineered insertion tubes, flexible tip bending angles, and specialized biopsy channels, the endoscope system facilitates seamless diagnostic examinations and tissue sampling.
Supported by customizable technical configurations and optional OEM services, the portable video endoscopy system is an ideal solution for clinics, hospital wards, and mobile medical centers.
Key Features
1,000,000 Pixels CMOS HD Imaging
High-resolution 1,000,000-pixel CMOS sensor delivers exceptional clarity and fine mucosal detail for diagnostic precision.
Integrated Portable Screen Display
Equipped with a compact, head-mounted portable display screen for convenient real-time viewing without extra large monitors.
Dual Gastroscope & Colonoscope Options
Offers specialized gastroscope and colonoscope insertion scopes tailored for upper and lower GI examinations.
Wide View of Field & Flexible Deflection
Features a wide 140° field of view and multi-directional tip deflection for effortless navigation through anatomical structures.
Optimized Biopsy Channels
Includes dedicated working channel diameters (Ø2.8mm for gastroscope; Ø3.2mm / 3.7mm for colonoscope) to accommodate diagnostic accessories.
Customizable OEM Solutions
Supports flexible technical detail customization and OEM service options to meet specific clinical requirements.
Technical Specifications
| Technical Parameter | Gastroscope Specification | Colonoscope Specification |
|---|---|---|
| Diameter of Distal-end | Ø9.2mm / 9.8mm | Ø13.0mm |
| Diameter of Insert Tube | Ø9.0mm / 9.6mm | Ø12.8mm |
| Biopsy Channel | Ø2.8mm | Ø3.2mm / 3.7mm |
| Working Length | 1030mm | 1330mm |
| Total Length | 1330mm | 1630mm |
| View of Field | 140° | 140° |
| Depth of View | 3-100mm | 3-100mm |
| Resolution | 1,000,000 CMOS | 1,000,000 CMOS |
| Tip Deflection | U:210° D:90° L/R:100° | U:180° D:180° L/R:160° |
- Specifications are based on the official technical datasheets for the Portable HD Video Endoscopy Series.
- OEM service is available, and technical details can be customized upon request.
- Standard configuration includes the portable light source, control unit, screen display, and video scope.
Applications
Upper Gastrointestinal Screening
Provides detailed structural evaluation for esophagus, stomach, and duodenum examinations using the video gastroscope.
Colorectal Evaluations
Supports lower GI screening, mucosal assessment, and polyp identification using the video colonoscope.
Bedside & Outpatient Interventions
Portable design with built-in screen allows fast setup for hospital wards, emergency departments, and outpatient clinics.
System Configuration
The Portable HD Video Gastroscope & Colonoscope System is supplied complete with the portable processor unit, light source, display screen, insertion scope, and connection cables.
Please confirm your required scope configuration (Gastroscope or Colonoscope) and custom specification requests prior to placing an order.
Before Ordering
- Required order quantity and destination country.
- Scope model selection: Video Gastroscope and/or Video Colonoscope.
- Custom technical requirements or OEM branding preferences.
Request a Portable Endoscopy Quote
Contact UMY Medical to discuss system configurations, pricing, and export delivery for your clinic or hospital.
Frequently Asked Questions
What resolution does the portable endoscope system offer?
The system features a 1,000,000-pixel CMOS HD sensor for both gastroscopy and colonoscopy.
What are the working lengths of the scopes?
The working length is 1030mm for the gastroscope and 1330mm for the colonoscope.
Can technical parameters be customized?
Yes, OEM services are supported and technical specifications can be customized to suit your requirements.
What is the tip deflection angle for the gastroscope?
The gastroscope supports tip deflection of Up: 210°, Down: 90°, and Left/Right: 100°.
