UMALZ006 Semi-Automatic Coagulation Analyzer
The UMY Medical UMALZ006 is a single-channel, semi-automatic coagulation analyzer for laboratories performing routine coagulation tests. Its optical light-scattering measurement system is designed for PT, APTT, thrombin time (TT), fibrinogen and clotting factor testing, with operator-managed sampling and reagents.
The system includes a 240 × 128 LCD, built-in thermal printer and RS232 connection for external PC-based result management. A PT-derived fibrinogen procedure and an electronically linked pipette are described as optional features in the supplied product sheet.
Key Features
Optical Coagulation Measurement
Uses a scattered-light optical measurement principle for routine coagulation analysis.
Single-Channel Bench-Top Workflow
A compact semi-automatic system with a dedicated test channel and sample/reagent preparation workflow.
LCD Display and Result Storage
240 × 128 LCD display, with memory for up to 10,000 test results according to the supplied specifications.
Result Printing and PC Connection
Integrated thermal printer and RS232 interface for connection to compatible PC management software.
Optional Functions
PT-derived fibrinogen testing and an electronically linked pipette are available as options; inclusion must be confirmed in the quotation.
Routine Coagulation Test Menu
The product sheet identifies the following test categories. Confirm assay procedures, reagent selection, quality controls and calibration requirements for your intended use.
| Test | Common abbreviation |
|---|---|
| Prothrombin time | PT |
| Activated partial thromboplastin time | APTT |
| Thrombin time | TT |
| Fibrinogen | FIB (including optional PT-derived method) |
| Clotting factor tests | Assay-dependent; confirm the specific factor and reagents |
Technical Specifications
| Model | UMALZ006 |
|---|---|
| Product type | Semi-automatic coagulation analyzer |
| Measurement principle | Optical scattered-light measurement |
| Test channels | 1 |
| Display | 240 × 128 LCD |
| Result memory | Up to 10,000 test results |
| Printer | Built-in thermal printer |
| Data interface | RS232 for PC connection |
| PT-derived fibrinogen method | Optional |
| Electronically linked pipette | Optional |
| Electrical supply | 220 VAC ±15%, 50–60 Hz (per supplied sheet) |
| Dimensions (L × W × H) | 370 × 370 × 120 mm (per supplied sheet) |
The source sheet’s tabulated sample/reagent volume and some temperature/performance rows have unclear label alignment. These values require supplier confirmation and are intentionally not stated as fixed specifications here.
Where This Analyzer Fits
UMALZ006 may be considered for clinical laboratories that perform routine coagulation testing and have personnel available to carry out the manual pipetting and preparation steps associated with a semi-automatic instrument. Buyers should compare daily sample volume, peak workload and staff requirements with fully automatic systems before selecting a configuration.
For an alternative semi-automatic model, see UMALZ033 Semi-Automatic Coagulation Analyzer. For automated reagent and sample handling, review the UMH-1000C Fully Automatic Coagulation Analyzer.
Before Ordering
- List the required tests (PT, APTT, TT, FIB and any specific clotting factors), expected daily test volume and laboratory type.
- Confirm reagent system, sample and reagent volumes, pre-warming positions and quality-control materials with the sales team.
- Confirm whether the optional PT-derived method and linked pipette are included.
- Specify destination country, power supply, documentation and result-management needs.
Request a UMALZ006 Coagulation Analyzer Quotation
Share your required tests, daily sample volume, destination country and preferred configuration for a product specification and quotation.
Frequently Asked Questions
Is the UMALZ006 a fully automatic coagulation analyzer?
No. UMALZ006 is a semi-automatic, single-channel instrument. For a fully automatic option, review UMH-1000C.
Which tests are listed for the UMALZ006?
The supplied document lists PT, APTT, TT, fibrinogen and clotting factor testing. Confirm each intended test and the matching reagent procedure before ordering.
Does it have a printer and a PC interface?
Yes. The supplied specification lists an integrated thermal printer and RS232 interface for PC management software.
Are the pipette and PT-derived fibrinogen method included?
They are listed as optional features. Confirm their inclusion and any required accessories in the quotation.
