UMDX011 RV-150RH Portable X-ray Machine for Dental and Point-of-Care Imaging
The UMDX011 Portable X-ray Machine is a compact, lightweight radiography unit designed for dental clinics, hospital wards, emergency departments and other point-of-care imaging environments. Based on the RV-150RH platform, the system combines advanced 100kHz high-frequency generator technology with a precise 0.4mm micro-focus X-ray tube to deliver sharp, consistent imaging with low radiation exposure.
Weighing only 1.9kg, the UMDX011 is easy to carry and position for bedside, chairside and field use. User-friendly digital touch controls, quick exposure response and integrated safety features support efficient daily workflows in dental and general medical applications.
Key Features
Advanced 100kHz High-Frequency Technology
Delivers stable high-voltage output with a kV ripple of less than 1% and an inverting frequency above 100kHz, supporting consistent image quality.
0.4mm Micro-Focus Tube
A precise 0.4mm focal spot provides sharp image detail, making the unit suitable for fine dental and medical radiography.
1.9kg Lightweight Design
A compact and portable body weighing approximately 1.9kg enables easy transport and flexible positioning at the chairside, bedside or in field conditions.
User-Friendly Digital Touch Controls
Intuitive digital touch interface simplifies parameter setting and exposure operation for routine clinical use.
Quick Exposure Response
Exposure time of 0.01–2 seconds supports fast imaging workflows and reduced patient waiting time.
Strong Safety Features
Designed with operator and patient safety in mind for dental and medical point-of-care radiography environments.
Imaging Performance
The UMDX011 is built around a high-frequency generator and micro-focus tube to provide reliable image quality for portable radiography.
Stable High-Voltage Output
kV ripple below 1% helps ensure consistent exposure output and reproducible image results.
Fine Detail Resolution
The 0.4mm focal spot supports clear visualization of fine anatomical structures in dental imaging.
Flexible Exposure Control
Exposure time adjustable from 0.01 to 2 seconds accommodates different examination types and patient conditions.
Clear Status Display
A segment code screen presents working parameters and system status in a simple, easy-to-read format.
Technical Specifications
| Specification | UMDX011 (RV-150RH) |
|---|---|
| Model | UMDX011 |
| Platform | RV-150RH Portable X-ray Machine |
| Product Type | Portable X-ray Machine |
| Tube Voltage | 60kV |
| Tube Current | 2mA |
| kV Ripple | < 1% |
| Inverting Frequency | > 100kHz |
| Focal Spot | 0.4mm |
| Exposure Time | 0.01 – 2 seconds |
| Screen | Segment code screen |
| Control | User-friendly digital touch controls |
| Weight | 1.9kg |
| Dimensions | 186 mm × 126 mm × 78.9 / 141 mm |
- Specifications are based on the supplied UMDX011 product brochure.
- The exact delivered configuration, accessories and power supply options must be confirmed before quotation.
- Users should follow local radiation safety regulations and applicable medical device registration requirements.
Applications
Dental Clinics
Supports chairside intraoral and portable dental radiography with sharp imaging and easy operation.
Hospital Wards
Lightweight design enables bedside imaging for patients who cannot be transported easily.
Emergency Departments
Quick exposure and portable operation support rapid imaging in emergency and point-of-care settings.
Field and Outreach Medical Services
Compact size and low weight make the unit suitable for mobile medical teams and outreach programs.
System Configuration
The UMDX011 is supplied as a portable X-ray unit with digital touch controls and segment code display. Please confirm the full scope of supply before ordering, including battery or power supply options, charging accessories, protective components and any required imaging accessories.
Buyers requiring specific exposure parameter presets, language options or local regulatory documentation should request the current datasheet and configuration list.
Before Ordering
- Required quantity and destination country.
- Intended application: dental, bedside, emergency or field use.
- Power supply and battery configuration requirements.
- Required accessories and imaging workflow setup.
- Software/interface language and display requirements.
- Training, technical support and warranty information.
- Local regulatory and tender documentation requirements.
Discover more options in our Radiological Equipment range.
Request a UMDX011 Portable X-ray Machine Quote
Contact UMY Medical to discuss the UMDX011 configuration, specifications and export quotation for your clinic or institution.
Please include your required quantity, destination country and intended application.
Frequently Asked Questions
What is the weight of the UMDX011?
The UMDX011 weighs approximately 1.9kg, making it easy to carry for bedside, chairside and field imaging.
What are the tube voltage and current of the UMDX011?
The UMDX011 operates at 60kV tube voltage and 2mA tube current, with a kV ripple below 1%.
Is the UMDX011 suitable for dental use?
Yes. With its 0.4mm micro-focus, compact design and easy touch controls, it is well suited for dental and other point-of-care radiography.
What is the exposure time range?
Exposure time is adjustable from 0.01 to 2 seconds, depending on the examination requirements.
