Handheld Waterproof Veterinary Ultrasound Scanner for Elite Animal Diagnostics

This handheld waterproof veterinary ultrasound scanner is a highly sought-after device for animal diagnostics, offering portability and ease of use in various environments. With high-quality imaging, it is ideal for diagnosing conditions in small and large animals, including pregnancy detection, abdominal issues, and musculoskeletal conditions. The scanner is designed to withstand tough veterinary environments, providing reliable results even in challenging conditions. Its compact size and waterproof feature make it the perfect tool for on-the-go diagnostics, enhancing productivity for veterinarians. This device is essential for quick and accurate assessments, ensuring the best care for animals.

Specific Parameters

编辑
ITEMS PARAMETERS
Probe Specifications
Probe Model 3.5C8050L Convex Probe
Detection Depth 140mm
Dead Zone 3 mm
Resolution (Horizontal) 2 mm (Depth 80mm)
Resolution (Vertical) 1 mm (Depth 80mm)
Geometric Location Accuracy (Horizontal) 10%
Geometric Location Accuracy (Vertical) 5%
Amplification Factor 1.0, 1.2, 1.5, 2.0
Technical Specifications
Scanning Manner Electronic convex array
Working Frequency 2.5MHz~5MHz
Display Mode B, B+B
Scanning Range Convex array 50°
Image Gray-Scale 256 levels
Scanning Line Number 512 lines/frame
Frame Rate 30 frames/second
Digital Scanning Conversion 512×512×8 bits
Display
Display Screen 5″ TFT
Physical Specifications
Overall Size 228mm × 143mm × 30mm
Total Weight 840g
Portable Battery
Battery Capacity 3000mAH / 7.4V
Continuous Work Over 2 hours
Power Consumption 7W
Storage >2G U flash disk

Product Details

In-Demand Handheld Waterproof Veterinary Ultrasound Scanner
In-Demand Handheld Waterproof Veterinary Ultrasound Scanner
In-Demand Handheld Waterproof Veterinary Ultrasound Scanner
Power Source

Electric

Material

Metal, Plastic

Device Classification

Class Ⅱ

MOQ

1

Transport Package

Carton

After-Sale Service

Online Technical Support

Warranty

1 Year

Origin

China

Production Capacity

3000 Sets/Year
