Color Doppler Ultrasound System Based on the uSeed Platform
The UMUS055 Color Doppler Ultrasound System is designed to provide remarkable performance in abdominal, gynecological, obstetrical, cardiac, small parts (breast, testes, thyroid, etc.), urological, musculoskeletal, and peripheral vascular examinations. The system combines advanced imaging technologies with an ergonomic, lightweight design to deliver superior image quality and an intuitive user experience.
The manufacturer highlights that the system is equipped with the second-generation uSeed metadata beamforming imaging technology platform developed by CPU+GPU heterogeneous computing technology, allowing images to be saved as metadata for post-processing. Together with an optional built-in battery, preposed USB ports supporting multi-data transmission, and DICOM 3.0 support, the system meets diverse clinical documentation and review needs. The current software version and applicable clinical reporting standards should be confirmed before ordering.
Examination records and images can be stored, reviewed, and printed, supporting routine clinical documentation and follow-up review workflows.
Key Features
uSeed Metadata Platform
Developed using CPU+GPU heterogeneous computing technology where images are saved as metadata for advanced post-processing.
Comprehensive Imaging Modes
Supports 2D, CFM, M, PW, CW, CMM, DPDI, B-steer, EFOV, and biopsy functions.
Advanced Imaging Technologies
Equipped with Pulse Inverse Harmonic Imaging (PIHI), Speckle Reduction Imaging (SRI), Spatial Compound Imaging (SCI), TSI, FCI, and HR flow.
Intelligent Measurements
Includes standard Auto IMT measurement, local and global amplification, and PW auto trace with auto calculation.
Ergonomic and Lightweight Design
Weighs only 7.5kg with a 12-inch medical LCD monitor supporting 90-degree rotation and a backlit keyboard.
Flexible Connectivity & Expansion
Features 2 activated probe connectors, 2 probe holders, preposed USB ports, and an optional customized trolley and built-in battery.
Advanced Imaging Technologies
The UMUS055 utilizes cutting-edge computing architecture and digital processing to enhance tissue definition and blood flow visualization.
Pulse Inverse Harmonic Imaging (PIHI)
Reduces distortion generated by the fundamental wave and significantly improves the signal-to-noise ratio.
Speckle Reduction Imaging (SRI)
Significantly reduces unwanted speckle and provides enhanced tissue boundaries and echoes for confident diagnosis.
Spatial Compound Imaging (SCI)
Provides better contrast resolution, reduces speckle noise, and smooths imaging of homogeneous tissue.
Efficient Workflow Support
Supports Dual Live and multi-synchronization technologies, plus Q Save for parameter saving and presetting.
Technical Specifications
| Specification | UMUS055 |
|---|---|
| Model | UMUS055 |
| Product Type | Color Doppler Ultrasound System |
| Imaging Platform | uSeed Platform (CPU+GPU heterogeneous computing) |
| Monitor | 12-inch medical LCD monitor with 90-degree rotation |
| Weight | 7.5 kg (Light-weight) |
| Imaging Modes | 2D, CFM, M, PW, CW, CMM, DPDI, B-steer, EFOV, Biopsy |
| Advanced Technologies | THI, SRI, SCI, TSI, FCI, HR flow, PIHI |
| Hardware Interfaces | 2 Activated Probe Connectors, 2 Preposed USB Ports, DICOM 3.0 |
| Optional Accessories | Customized Trolley, Built-in Battery |
- Specifications are based on the supplied UMUS055 technical documentation.
- Some measurement definitions and software configurations require confirmation against the current software version.
- The exact delivered system configuration and included accessories must be confirmed before quotation.
- Medical facilities should evaluate applicable clinical protocols and destination-market regulatory requirements.
Applications
Abdomen and Urology
Provides remarkable performance and precise imaging for abdominal organs and urological evaluations.
Obstetrics and Gynecology
Supports routine screening and detailed biometric measurements in OB/GYN departments.
Cardiology and Peripheral Vascular
Supports four-chamber CW mode, CCA PW auto trace, and vascular blood flow analysis.
Small Parts and Musculoskeletal
Enables high-resolution imaging of breast, testes, thyroid, joints, tendons, and other small parts or musculoskeletal structures.
System Configuration
The UMUS055 is supplied with a 12-inch rotating medical monitor, 2 activated probe connectors, a backlit keyboard, and the advanced uSeed imaging platform.
Please confirm the full scope of supply before ordering. In particular, confirm whether specific probe types (convex, linear, phased array, etc.), customized trolley, built-in battery, printer, and software licenses are included in the selected quotation.
Buyers requiring specific measurement packages or language options should request the current software specification sheet.
Before Ordering
To confirm the appropriate UMUS055 configuration and prepare an accurate quotation, please provide the following information:
- Required quantity and destination country.
- Intended application: general imaging, OB/GYN, cardiology, or point-of-care mobile use.
- Required probe selection (convex, linear, intracavity, or phased array probes).
- Whether a built-in battery and customized trolley are needed.
- Software language and DICOM data-management requirements.
- Power supply and plug type requirements.
- Required training, technical support, and warranty information.
- Any local regulatory or tender documentation requirements.
Request a UMUS055 Ultrasound System Quote
Contact UMY Medical to discuss the UMUS055 configuration, probe options, software functions, and export quotation for your facility.
Please include your required quantity, destination country, and intended application. If you have specific technical requirements, our team can review them before preparing a quotation.
Frequently Asked Questions
What imaging platform does the UMUS055 use?
The UMUS055 is equipped with the second-generation uSeed platform, developed via CPU+GPU heterogeneous computing technology with metadata image saving.
What clinical applications does the UMUS055 support?
It provides remarkable performance in abdomen, gynecology, obstetrics, cardiology, small parts (breast, testes, thyroid), urology, musculoskeletal, and peripheral vascular examinations.
Is the system portable and lightweight?
Yes, it features a lightweight design of only 7.5kg, a 12-inch medical LCD monitor with 90-degree rotation, and optional built-in battery and trolley support.
Does it support automatic measurements?
Yes, it features standard Auto IMT measurement as well as PW auto trace and auto calculation functions.
