Properties: Diagnosis & Injection
Item: Vet video endoscope
Contrast adjustment: 0-128
Metering mode: AVE/PEAK
Image enhance: 0-30
White balance: Auto/manual white balance
Vessel capacity: Not less than 1 l
Maximum suction volume: 20 L / Min
Top diameter: ≤ 8.0mm
Item: Vet video endoscope
Contrast adjustment: 0-128
Metering mode: AVE/PEAK
Image enhance: 0-30
White balance: Auto/manual white balance
Vessel capacity: Not less than 1 l
Maximum suction volume: 20 L / Min
Top diameter: ≤ 8.0mm
Product Details
| 1-1 | Top diameter | ≤Φ8.0mm |
| 1-2 | Input tube | ≤Φ8.0mm |
| 1-3 | Biopsy channel | ≥Φ2.0mm |
| 1-4 | Working length | ≥1500mm |
| 1-5 | Total length | ≥1800mm |
| 1-6 | Field of view | ≥140º |
| 1-7 | Depth of field | ≥3-100mm |
| 1-8 | Image solution | ≥480000pixels (CCD) |
| 1-9 | Bending angles | ≥ up210º down≥90º left&right≥100º maximum 230 |
| 1-10 | Image frozen | 16 images frozen,stroe,playback. |
| 1-11 | warranty | One year |
| 2-1 | Contrast adjustment | 0-128 |
| 2-2 | Image adjustment | color adjustment level: 0-128,vessel enhancement |
| 2-3 | Metering mode | AVE/PEAK |
| 2-4 | Image enhance | 0-30 |
| 2-5 | White balance | Auto/manual white balance |
| 2-6 | Pump | pressure 30-80Mpk,air supply 4L/min-10L/min |
| 2-7 | illuminance | ≥200000Lx,LED light source 30000hours life. |
