Aviation-Grade Carbon Fiber Micro Pressure Hyperbaric Oxygen Chamber with ARM Smart Control
Quick Info.
Power Source: Electric
Warranty: 1 year
After-sale Service: Online service and delivering spare parts
Transport Package: Carton or Wooden Cases
Material: Metal, Plastic
Origin: Guangzhou City, Guangdong, China
Instrument Classification: Class Ⅱ
Quality System Standard: ISO13485
- SKU NO.: UMY-OC-005
- Warranty: 1 Year
- Origin: Guangzhou City, Guangdong, China
Engineered for the most demanding wellness and recovery environments, this micro pressure hyperbaric oxygen chamber sets an entirely new standard through its aviation-grade carbon fiber composite construction, French imported lithium-based molecular sieve oxygen system, and an ARM expandable main control platform. The carbon fiber oxygen therapy chamber body features two φ600 mm aviation portholes, an explosion-proof aviation PC door, and an artistic eco-friendly crystal paint surface available in blue, green, black with carbon patterns, or custom finishes — giving facility operators a product that is as visually commanding as it is technically superior. The 10-inch smart all-in-one control screen operates all cabin functions from both inside and outside, with wireless intercom and dual LED cold light source included as standard.
Purpose-built performance for elite commercial deployment:
Two-speed adjustable pressurization from 10–90 kPa, intelligent continuous fresh air circulation at 240 L/min, and six-stage air purification combine to create an oxygen environment that is both medically consistent and experientially superior for high-frequency daily sessions. The 93±3% oxygen concentration at 10 L/min output is sustained by a domestic oil-free compressor and French molecular sieve system that requires minimal servicing between sessions.
Smart hyperbaric oxygen therapy as a flagship facility investment:
Smart hyperbaric oxygen therapy at this specification tier delivers a measurable return on investment for luxury operators, as the zero-gravity electric leather sofa, six-mode massage system, and cold water air conditioning create a session experience that commands premium per-use pricing in any market. The integrated assembly design at W1170×D2000×H1850 mm and 380 kg build weight signals permanence, quality, and serious capital investment to any client who enters the space.
Operators can complement this chamber with the Medical Oxygen Concentrator Single Flow 10L Dual Flow 20L Integrated Nebulizer for Homecare and Clinical Use for a comprehensive oxygen wellness offering. This micro pressure hyperbaric oxygen chamber is the ultimate choice for operators who position oxygen therapy as a premium, differentiated service.
The Specific Parameters
| ITEMS | PARAMETERS |
|---|---|
| Physical Specifications | |
| Standard capacity | 1 person, 4.3m³ |
| External dimensions | W1170×D2000×H1850mm |
| Weight | 380 KG |
| Cabin material | Carbon fiber composite material |
| Sealed cabin door | Aviation aluminum alloy automatic telescopic hinge + PC explosion-proof door |
| Core Host Assembly | |
| Oxygen Generation System | 93(±3)%, 10L/min |
| Pressure control | 10-50 KPA (Up to 90 KPA for overseas version) |
| Pressurization Mode | Two-speed adjustable |
| Fresh air circulation | Intelligent continuous non-stop 240 L/min |
| Air Purification | Six-stage filtration |
| In-cabin Configuration | |
| Operating System | 10-inch smart all-in-one control screen (inside/outside) |
| Sofa Type | Zero-gravity electric leather sofa |
| Air Conditioning System | Special oxygen cabin air conditioner with six-mode massage |
| Inhalation Method | Diffusion / Nasal inhalation |
| Communication System | Wireless intercom |
| Color Options | Blue, green, black (with carbon patterns), or custom colors |
Feature list for UMY-OC-005
* Aviation-Grade Carbon Fiber Composite with Custom Color Finish Options
* French Imported Lithium-Based Molecular Sieve for 93±3% Oxygen Output
* ARM Smart Control System with Expandability and Dual Inside-Outside Screen
* Zero-Gravity Electric Leather Sofa with Six-Mode Massage and Cold Water AC
* 240 L/min Continuous Intelligent Fresh Air Circulation with Six-Stage Purification
Application
Designed for ultra-premium wellness suites, luxury hotel recovery programs, private executive health centers, high-end aesthetic clinics, and premium medical recovery facilities that require aviation-grade construction, smart system integration, and a fully curated first-class oxygen therapy environment.
Q1: Are custom exterior color finishes available for facilities requiring a specific branding or interior design alignment?
A1: Yes, the chamber is available in blue, green, black with carbon patterns, or fully custom colors to match any facility interior design or branding specification.
Q2: How does the aviation aluminum alloy automatic telescopic door hinge contribute to the structural sealing performance of the chamber?
A2: The aviation aluminum alloy hinge mechanism ensures a precise, repeatable door seal with every closure, maintaining the chamber’s pressure integrity across thousands of operational cycles.
Q3: What is the lead time for custom-finish units, and where can the full commercial oxygen product range be explored?
A3: Lead times for custom color configurations vary and are confirmed at order stage; the full human-use oxygen product range can be browsed on the Oxygen Machine category page.
