This animal semen analyzer is developed for veterinary fertility evaluation with a focus on practical data analysis and efficiency. It combines image based assessment with comprehensive semen data to support accurate reproductive diagnostics. The system analyzes sperm motion paths, velocity distribution, and abnormal sperm parameters in a structured workflow. Flexible acquisition time and large data storage support repeated testing and comparative analysis. Printed and digital reports present results clearly, helping users interpret outcomes at a glance. Its efficient configuration makes it suitable for cost conscious veterinary and breeding operations.
For users expanding diagnostic capabilities, it pairs well with Full Digital Ultrasound Scanner for reproductive assessment.
This analyzer delivers dependable performance for routine and advanced animal fertility testing.
Specific Parameters
| ITEMS | PARAMETERS |
|---|---|
| Product Overview | |
| Product Type | Veterinary Portable Semen Analyzer |
| Primary Function | Automated analysis of animal sperm motility, concentration, and morphology |
| Motility Analysis | |
| Analysis Parameters | VAP average path velocity; VCL track speed; VSL straight velocity; ALH head swing frequency; BCF flagellar beat frequency; LIN linearity VSL/VCL; STR straightness index; WOB wobble index |
| Trajectory Analysis | Single sperm trajectory tracking with kinetic parameter calculation |
| Image Handling | Save and generate images for future reference and analysis |
| Concentration Analysis | |
| Detection Standard | Automatic sperm concentration detection according to WHO standard |
| Concentration Metrics | Sperm per milliliter concentration and overall density |
| Count Types | Total static sperm count Type D; forward movement count Type A and B; total motile count Type A B C |
| Morphology Analysis | |
| Analysis Mode | Monochromatic mode for sperm head deformity identification |
| Head Parameters | Head area, perimeter, length, and width |
| Midpiece Parameters | Middle section area and width |
| Embedding Metrics | Central embedding distances and angles |
| Tail Evaluation | Normal tail identification and assessment |
| Software System | |
| Operating System | Windows XP with Chinese and English interface |
| Capture Method | Medical dedicated capture card supporting single field, single frame, and continuous frame acquisition |
| Image Processing | High resolution image capture with static and dynamic sperm analysis |
| Data Functions | Statistical analysis, visual analysis, query, modification, storage, and report printing |
| Standard Configuration | |
| Computer | Laptop Lenovo 1 pc |
| Camera | Camera China 1 pc |
| Microscope | Binocular Microscope 1 pc |
| Analysis Software | Microscope Analysis Software 1 pc |
| Accessories | Counting Plate 1 pc; Sperm Thermostat 1 pc; Microscope Slide 1 pc |
| Documentation | User Manual 1 pc |
Product Details
- Comprehensive Semen Motion Analysis: Advanced analysis system provides detailed evaluation of sperm motility and movement characteristics for accurate reproductive assessment.
- Precise Velocity Statistics: Supports comprehensive sperm velocity measurement and tracking to improve fertility evaluation accuracy and diagnostic reliability.
- High-Speed Image Acquisition: Equipped with rapid image capture technology to ensure smooth analysis of sperm movement and dynamic sample observation.
- Flexible Sampling Capability: Supports various sample preparation and analysis methods to meet diverse veterinary reproductive testing requirements.
- Clear Diagnostic Reporting: Generates easy-to-read diagnostic reports with organized data presentation for efficient clinical interpretation and documentation.
- Advanced Data Visualization: Provides intuitive graphical analysis and visual statistics to simplify result interpretation and improve workflow efficiency.
- Stable System Performance: Designed for continuous daily veterinary use with reliable operational stability and consistent analytical accuracy.
- User-Friendly Operation Interface: Intuitive software system simplifies examination procedures and enhances laboratory workflow management.
- Efficient Laboratory Workflow: Fast processing capability supports rapid semen analysis and improves productivity in busy veterinary clinics and laboratories.
- Ideal for Veterinary Reproductive Applications: Suitable for animal hospitals, breeding centers, veterinary laboratories, and reproductive research facilities requiring professional semen analysis solutions.
- High-Quality Veterinary Microscope: Designed for detailed cellular and tissue analysis in veterinary laboratories, providing reliable performance for small animal diagnostics.
- Trinocular Optical System: Equipped with three viewing ports for simultaneous observation and camera integration, enhancing imaging versatility.
- Precision Optical Lenses: High-quality objective and eyepiece lenses deliver sharp, clear images for accurate microscopic examination.
- Stable Mechanical Stage: Smooth and adjustable stage allows precise specimen positioning for consistent and accurate observation.
- Multi-Illumination Options: Integrated light source with adjustable intensity provides clear visualization under various magnification levels.
- Durable and Reliable Construction: Built with high-quality materials to withstand daily laboratory use and maintain consistent performance.
- Ergonomic Design: Optimized layout for user comfort during long observation sessions, reducing operator fatigue.
- High Magnification Capability: Supports a wide range of magnification levels suitable for cellular, tissue, and blood analysis in veterinary applications.
- Camera Integration Ready: Compatible with digital cameras for image capture, recording, and remote observation.
- Ideal for Veterinary Laboratories: Suitable for animal hospitals, research labs, and diagnostic centers performing small animal cytology, hematology, and histology examinations.
