Wireless Linear Ultrasound Scanning for Point-of-Care Diagnosis
The UMUS041 B/W Wireless Probe Type Ultrasound Scanner is designed to support rapid ultrasound examination in emergency departments, anesthesia, bedside care, clinics and field medical environments. The system uses a 128-element linear probe with 10/14MHz frequency to provide clear B-mode and B/M-mode imaging without a probe cable.
The probe connects wirelessly to smartphones, tablets and Windows devices, allowing operators to work freely during examinations. Images and videos are stored directly on the connected mobile device, and measurement functions cover distance, area, obstetrics and other routine clinical needs.
The manufacturer describes an advanced digital imaging technology with a waterproof design for convenient sterilization. Current software version, compatible devices and delivered accessories should be confirmed before ordering.
Key Features
Wireless Design Without Probe Cable
WiFi wireless connection allows free probe movement without cable restrictions during examinations.
Advanced Digital Imaging
Advanced digital imaging technology provides clear ultrasound images in B and B/M display modes.
128-Element Linear Probe
A 128-element electronic linear array probe operates at 10/14MHz for superficial imaging applications.
Small and Lightweight
At only 220g and 156mm × 60mm × 20mm, the probe is easy to carry for bedside and field use.
Waterproof, Sterilization-Friendly Design
Waterproof construction allows convenient cleaning and sterilization between examinations.
Remote Diagnostic Convenience
Images and videos are stored on mobile phones and tablet PCs for easy transfer and remote consultation.
Imaging and Measurement Performance
The UMUS041 provides B-mode and B/M-mode imaging with adjustable scanning depth for superficial tissue examination.
B and B/M Display Modes
Supports real-time B-mode imaging and B/M mode for motion analysis along the M-line.
Adjustable Scanning Depth
Linear scanning depth is adjustable across 20/30/40/55mm to match different examination requirements.
256-Level Gray Scale
256-level image gray scale supports detailed tissue differentiation in B-mode images.
Built-In Measurements
Distance, area, obstetric and other measurement functions support routine clinical calculations.
Examination and Measurement Parameters
The supplied UMUS041 documentation lists the following examination functions. Exact software functions and measurement packages should be confirmed using the current app version.
| Parameter Category | Supplier-Listed Values |
|---|---|
| Scan Mode | Electronic array, electronic linear array scanning |
| Probe Frequency | Linear probe 10/14MHz |
| Elements | 128 elements |
| Field of View | Linear L25 |
| Scanning Depth | Linear 20/30/40/55mm, adjustable |
| Display Mode | B, B/M |
| Image Gray Scale | 256 level |
| Frame Rate | 16f/s |
| Measurement | Distance, area, obstetrics and other |
Technical Specifications
| Specification | UMUS041 |
|---|---|
| Model | UMUS041 |
| Product Type | B/W Wireless Probe Type Ultrasound Scanner |
| Scan Mode | Electronic array, electronic linear array scanning |
| Frequency | Linear probe 10/14MHz |
| Elements | 128 elements |
| Field of View | Linear L25 |
| Scanning Depth | Linear 20/30/40/55mm, adjustable |
| Screen | Smart phone or tablet screen |
| Supporting System | iOS, Android, Windows |
| Display Mode | B, B/M |
| Frame Rate | 16f/s |
| Image Gray Scale | 256 level |
| Image/Video Storage | Store on mobile phones, tablet PC |
| Measurement | Distance, area, obstetrics and other |
| Power | Built-in lithium battery, 4200mAh |
| Battery Working Time | 3 hours |
| Size | 156mm × 60mm × 20mm |
| Net Weight | 220 gram |
| Certifications (per catalog) | FDA, TÜV, CE 0123 |
- Specifications are based on the supplied UMUS041 product catalog.
- Compatible app versions, supported devices and wireless performance should be confirmed before ordering.
- Optional accessories shown in the catalog — needle puncture guide, Android tablet/iPad, tablet bracket and trolley — are not part of the standard configuration unless confirmed.
- Buyers should evaluate applicable clinical protocols and destination-market regulatory requirements.
Standard Configuration and Options
The catalog lists the following standard configuration. Operator-facing functions are implemented through the companion app on the connected smart device.
Standard Configuration
Wireless probe device 1 unit, built-in battery and charge cable 1 set, and user manual 1 copy.
Needle Puncture Guide
An optional needle puncture guide supports guided puncture and interventional procedures.
Display Options
Optional Android tablet or iPad with bracket can be configured as a dedicated display.
Trolley Option
An optional trolley provides mobile mounting for the display in ward and emergency environments.
Applications
Emergency and Bedside Care
Rapid wireless scanning supports bedside examination of patients who are difficult to transport.
Anesthesia and Puncture Guidance
With the optional needle guide, the probe supports vascular access and nerve block procedures.
Superficial Tissue Imaging
The 10/14MHz linear probe is suited for superficial tissue and small organ examination.
Remote and Field Medicine
Wireless connectivity and mobile storage support remote diagnosis and image transfer in field conditions.
Outpatient Clinics
A high cost-performance, cable-free design suits routine screening in small clinics and mobile medical services.
System Configuration
The UMUS041 is described as a wireless probe-type ultrasound scanner working with smartphones, tablets and Windows devices via WiFi.
Please confirm the full scope of supply before ordering. In particular, confirm whether the needle puncture guide, display tablet, tablet bracket, trolley and additional accessories are included in the selected quotation.
Buyers requiring specific app functions, measurement packages or language versions should request the current app specification before purchase.
Before Ordering
To confirm the appropriate UMUS041 configuration and prepare an accurate quotation, please provide the following information:
- Required quantity and destination country.
- Intended applications: bedside, emergency, anesthesia, puncture guidance or superficial imaging.
- Whether the needle puncture guide, tablet, bracket or trolley is required.
- Target smart devices and operating systems in use (iOS, Android or Windows).
- Required app functions, measurement packages and report formats.
- Language and data-management requirements.
- Charging and power supply requirements.
- Required training, technical support and warranty information.
- Any local regulatory or tender documentation requirements.
Explore our
Medical Equipment
</a >
range.</p >
Request a UMUS041 Wireless Ultrasound Scanner Quote
Contact UMY Medical to discuss the UMUS041 configuration, optional accessories, app functions and export quotation for your facility.
Please include your required quantity, destination country and intended applications. If you have specific technical or reporting requirements, our team can review them before preparing a quotation.
Frequently Asked Questions
How does the UMUS041 connect to a display?
The probe connects wirelessly via WiFi to smartphones, tablets or Windows devices, which serve as the display and operating terminal.
What imaging modes does the UMUS041 support?
The scanner supports B-mode and B/M-mode imaging with a 16f/s frame rate and 256-level gray scale.
How long does the battery last?
The built-in 4200mAh lithium battery provides approximately 3 hours of working time according to the catalog.
Is a needle puncture guide included?
The needle puncture guide is shown as an optional accessory. Buyers should confirm whether it is included in the quotation.
What measurements are available?
The app supports distance, area, obstetric and other measurement functions listed in the supplier documentation.
