High-Performance 17×17-Inch Wired Flat Panel Detector for Digital Radiography
The UMFPD009 Wired Flat Panel Detector is engineered to provide exceptional image quality and reliable performance for modern hospital digital radiography (DR) systems. Combining a 17 x 17-inch active area with direct deposited Cesium Iodide (CsI:Tl) scintillator technology and amorphous silicon TFT arrays, the system captures highly detailed diagnostic images with reduced radiation dose.
Equipped with advanced Full-Field Automatic Exposure Detection ($F^2AED$) technology, stable Gigabit Ethernet data transmission, and a durable anodized aluminum alloy housing, the UMFPD009 ensures seamless integration into various X-ray rooms and demanding clinical workflows.
Key Features
Direct Deposited CsI Technology
Utilizes high-efficiency direct deposited Cesium Iodide (CsI:Tl) scintillator to achieve superior detective quantum efficiency (DQE) and sharp image contrast.
Full-Field AED ($F^2AED$) Technology
Advanced automatic exposure detection technology enables flexible, reliable synchronization with various X-ray generators without physical trigger cables.
High Resolution & Fine Pixel Pitch
Features a 140 µm pixel pitch design and a 3072 × 3072 image matrix to capture delicate anatomical structures with high clarity.
Wide Dynamic Range
Offers a wide dynamic range exceeding 80 dB and a 16-bit A/D conversion depth for rich grayscale reproduction.
Gigabit Ethernet Interface
Provides stable, high-speed Gigabit Ethernet data transmission for rapid image acquisition and preview (2s–4s).
Durable Anodized Aluminum Housing
Built with a rugged, lightweight anodized aluminum alloy enclosure designed to withstand daily clinical use.
Technical Specifications
| Specification Category | Technical Parameters |
|---|---|
| Panel Technology | Amorphous Silicon Active TFT/Diode Array |
| Scintillator | Direct Deposit CsI:Tl |
| Active Area | 430 mm × 430 mm (17″ × 17″) |
| Image Matrix Size | 3072 × 3072 pixels |
| Pixel Pitch | 140 µm |
| A/D Conversion | 16 bits |
| Spatial Resolution | 3.57 lp/mm |
| Dynamic Range | > 80 dB |
| Data Interface | Gigabit Ethernet |
| Acquisition Time | 2s – 4s |
| Trigger Type | AED / Manual Sync / Soft Sync / External Sync |
| Dimensions | 460 mm × 460 mm × 15 mm |
| Weight | ~3.9 kg |
| Housing Material | Anodized Aluminum Alloy |
| Power Supply & Consumption | 100–240V, 50/60Hz; Max. 45W |
- Specifications are based on the official technical documentation of the UMFPD009 wired flat panel detector.
- Verify network configuration, power supply standards, and workstation compatibility prior to order placement.
Applications
General Radiography Rooms
Ideal for hospital X-ray rooms performing routine chest, spine, abdomen, and skeletal examinations.
DR System Upgrades & Retrofitting
Transforms traditional analog X-ray tables and wall stands into high-performance digital imaging suites.
Specialized Diagnostic Imaging
Delivers high spatial resolution and wide dynamic range suitable for comprehensive clinical diagnostics.
Before Ordering
To ensure proper compatibility and prepare an accurate export quotation, please provide the following details:
- Required order quantity and destination country.
- Intended application: new DR system integration or existing room retrofitting.
- Whether acquisition software, computer workstation, or power accessories are required.
- Any local medical device regulatory or certification requirements.
Discover more options in our X-ray Flat Panel Detector range.
Request a UMFPD009 Detector Quote
Contact UMY Medical to discuss technical configurations, lead times, and export pricing for your digital X-ray project.
Please include your required quantity and destination hospital details so our sales team can assist you promptly.
Frequently Asked Questions
What is the active imaging area of the UMFPD009?
The UMFPD009 features a large 17 x 17-inch active imaging area (430 mm × 430 mm).
Does this detector support AED trigger mode?
Yes, it features advanced Full-Field Automatic Exposure Detection ($F^2AED$) technology as well as manual sync, soft sync, and external sync modes.
What data interface does it use for transmission?
It uses a high-speed Gigabit Ethernet interface for stable and rapid wired image data transmission.
