1360L Laboratory Refrigerator for 2–8°C Cold Storage
The UMH-L1360 is a high-capacity laboratory refrigerator designed for controlled storage within a 2–8°C temperature range. Its 1360L cabinet is configured with three glass doors and 15 shelves, providing organized refrigerated storage for laboratory, medical and related professional environments.
The refrigeration system uses compressor cooling with a Huayi compressor and R134a refrigerant. An LED digital temperature display allows routine monitoring, while audible and visual alarms provide an additional warning function during operation.
With external dimensions of 1800 × 745 × 1870 mm, the UMH-L1360 is suitable for facilities requiring large refrigerated storage capacity within a single upright cabinet.
Key Features
2–8°C Temperature Range
Designed for controlled refrigerated storage within a specified temperature range of 2°C to 8°C.
1360L Large Capacity
The large 1360L internal volume supports organized storage where substantial refrigerated cabinet capacity is required.
Three Glass Doors
The three-door configuration provides convenient visual access to stored contents and allows the cabinet to be divided into separate access zones.
15 Storage Shelves
Fifteen shelves provide multiple storage levels for organizing refrigerated materials inside the cabinet.
Compressor Cooling
The refrigerator uses a compressor-based cooling system with a Huayi compressor.
LED Digital Display
The temperature controller uses an LED digital display for convenient routine temperature monitoring.
Audible and Visual Alarm
The unit is equipped with sound and light alarm functions to provide an additional operational warning.
Powder-Coated Steel Cabinet
Both the exterior and interior are constructed from cold-rolled steel with a sprayed protective finish.
Typical Applications
- Hospital and clinical laboratory refrigerated storage.
- Research laboratory cold storage.
- Medical facility refrigerated storage.
- Laboratory reagent and material storage where a 2–8°C environment is required.
- Large-capacity refrigerated storage in professional healthcare and research facilities.
Always confirm that the required storage temperature of the intended material is compatible with the specified 2–8°C operating range before use.
Temperature and Refrigeration System
| Temperature Range | 2–8°C |
|---|---|
| Cooling System | Compressor Cooling |
| Compressor | Huayi |
| Refrigerant | R134a |
| Temperature Controller | LED Digital Display |
| Alarm System | Yes |
| Alarm Method | Audible and Visual / Sound + Light |
| Noise Level | 52 dBA |
Technical Specifications
| Model | UMH-L1360 |
|---|---|
| Product Type | Laboratory Refrigerator |
| Capacity | 1360 L |
| Temperature Range | 2–8°C |
| Power Supply | 220 V / 50 Hz |
| Rated Power | 650 W |
| Power Consumption | 7.8 kWh / 24 h |
| Door Configuration | Three Glass Doors |
| Shelves | 15 |
| Cooling System | Compressor Cooling |
| Compressor | Huayi |
| Refrigerant | R134a |
| Temperature Display | LED Digital Display |
| Alarm | Audible and Visual |
| Noise | 52 dBA |
| Exterior Material | Powder-Coated Cold-Rolled Steel |
| Interior Material | Powder-Coated Cold-Rolled Steel |
| External Dimensions | 1800 × 745 × 1870 mm |
| Internal Dimensions | 1680 × 610 × 1380 mm |
| Package Dimensions | 1890 × 810 × 2020 mm |
| Net Weight | 158 kg |
| Gross Weight | 190 kg |
Cabinet Design
Three-Zone Door Access
Three separate glass doors allow operators to access different sections of the refrigerator without opening the entire cabinet at once.
High-Capacity Shelf Layout
The internal cabinet incorporates 15 shelves for organized placement of refrigerated materials across multiple levels.
Large Upright Format
The upright cabinet provides 1360L of refrigerated capacity while maintaining a vertical installation footprint suitable for laboratory and medical environments.
Before Ordering
Please confirm your storage application and installation requirements before ordering the UMH-L1360.
- Required quantity.
- Destination country.
- Required storage temperature.
- Type of materials to be stored.
- Required voltage and plug configuration.
- Available installation space and doorway dimensions.
- Any tender or technical documentation requirements.
- Required shipping and packing terms.
Request a Laboratory Refrigerator Quote
Contact UMY Medical for configuration confirmation, quantity pricing, export quotation and project support for the UMH-L1360 laboratory refrigerator.
Send Your Requirements
Please provide the required quantity, destination country, storage application and any project or tender specifications.
Frequently Asked Questions
What is the temperature range of the UMH-L1360?
The specified operating temperature range is 2°C to 8°C.
What is the storage capacity?
The UMH-L1360 provides a nominal storage capacity of 1360 liters.
How many shelves are included?
The listed configuration includes 15 shelves.
Does the refrigerator include an alarm?
Yes. The listed configuration includes audible and visual alarm functions.
