The High-Pressure Injection System with Single or Dual Syringe Injector is designed for precise and controlled contrast agent delivery in CT, DSA, and MRI imaging procedures. This system allows for the flexible use of a single or dual syringe, providing optimal contrast for high-resolution imaging in a variety of diagnostic applications. Its high-pressure capability ensures efficient contrast delivery, which is critical for accurate imaging in cardiovascular, neurological, and oncological evaluations. The system’s ease of use and reliability make it an essential tool for healthcare professionals looking to enhance diagnostic accuracy and patient care during complex imaging procedures.
Specific Parameters
| ITEMS | PARAMETERS |
|---|---|
| Interface | Selectable in English, French, German, and Chinese |
| Flow Rate Range | 0.1 mL/sec to 10 mL/sec in 0.1 mL/sec increments |
| Syringe Capacity | 100 mL |
| Volume Range | 0.1 mL to syringe capacity in 0.1 mL increments |
| Pressure | |
| Preset Limit | 300 psi default, user settable from 50 to 350 psi in 1 psi increments |
| Display | Real-time pressure curve |
| Change Threshold | Stop injection if pressure changes suddenly |
| Alarm | Voice alarm and stop injection when over preset limit |
| Injection or Scan | |
| Delay | 0 to 3599 seconds in 1 sec increments |
| Autofill | Settable flow rate from 3 mL/sec to 8 mL/sec, volume from 10 mL to syringe capacity |
| Multi-Phase | 1-8 phases per injection |
| Pause Phase | 0 to 999 seconds in 1 sec increments |
| Hold Capability | More than 30 minutes |
| Storage Capabilities | 100 protocols |
| Injector Arm and Pedestal | |
| Length | 27.6″ (70.0 cm) |
| Width | 27.6″ (70.0 cm) |
| Height | 49.2″ (125.0 cm) |
| Weight | 16.5 kg |
| Color Touch Screen | |
| Dimension (L × W × H) | 4.55″ × 12.68″ × 9.77″ (11.55 cm × 31.8 cm × 24.81 cm) |
| Weight | 4.1 kg |
| Main Control Box | |
| Dimension (L × W × H) | 11.9″ × 7.4″ × 4.7″ (30.2 cm × 9.1 cm × 12 cm) |
| Weight | 6.2 kg |
Product Details
- High-Pressure Injection System: Designed for precise and controlled contrast agent delivery during CT, DSA, and MRI imaging procedures.
- Single or Dual Syringe Compatibility: Allows flexible use of one or two syringes to optimize contrast distribution and enhance imaging quality.
- Accurate Contrast Delivery: Provides consistent and reliable contrast injection for high-resolution imaging across various diagnostic applications.
- High-Pressure Capability: Ensures efficient contrast media delivery, critical for detailed cardiovascular, neurological, and oncological imaging studies.
- Optimized for Diagnostic Accuracy: Enhances imaging performance by delivering precise contrast flow rates and volumes, supporting accurate evaluation.
- User-Friendly Operation: Intuitive controls and easy setup streamline workflow, allowing healthcare professionals to operate efficiently during complex imaging procedures.
- Programmable Injection Protocols: Supports customizable injection settings for different patient and imaging requirements.
- Reliable and Durable Design: Constructed with high-quality components to ensure stable performance and long-term clinical use.
- Efficient Clinical Workflow: Reduces preparation and injection time, improving throughput and patient care in busy imaging departments.
- Versatile Imaging Applications: Ideal for CT scans, DSA procedures, and MRI contrast studies, supporting cardiovascular, neurological, oncological, and general diagnostic evaluations.
- Integrated Safety Features: Includes pressure monitoring and alarm systems to ensure safe and controlled contrast administration.
- Consistent Performance Across Patients: Maintains accurate injection parameters regardless of patient size or imaging modality.
- High-Speed Injection Capability: Supports rapid delivery of contrast media when required for time-sensitive imaging sequences.
- User-Friendly Operation: Intuitive controls and easy setup streamline workflow, allowing healthcare professionals to operate efficiently during complex imaging procedures.
- Programmable Injection Protocols: Supports customizable injection settings for different patient and imaging requirements.
- Reliable and Durable Design: Constructed with high-quality components to ensure stable performance and long-term clinical use.
- Efficient Clinical Workflow: Reduces preparation and injection time, improving throughput and patient care in busy imaging departments.
- Versatile Imaging Applications: Ideal for CT scans, DSA procedures, and MRI contrast studies, supporting cardiovascular, neurological, oncological, and general diagnostic evaluations.
- Integrated Safety Features: Includes pressure monitoring and alarm systems to ensure safe and controlled contrast administration.
- Consistent Performance Across Patients: Maintains accurate injection parameters regardless of patient size or imaging modality.
- High-Speed Injection Capability: Supports rapid delivery of contrast media when required for time-sensitive imaging sequences.
Detail Gallery
