This portable dental X-ray machine delivers 140W imaging power in a compact, battery-powered form. The handheld dental X-ray features a 2.5-inch touchscreen and 360° dual-plane positioning. Three 2500mAh lithium batteries support cordless mobile clinic and outreach operation.
Long-lasting performance with reduced operating costs:
High-frequency tubes with 60,000+ hour lifespan ensure consistent image quality and low maintenance. At 70kV/2mA, high transmission power cuts exposure time and reduces imaging artifacts.
A safety-first solution for global dental programs:
Dental imaging safety is met with 99.9% lead shielding and sub-0.25mGy/h radiation leakage. Quick-lock screen and auto-termination protect operators from accidental radiation exposure.
Pair it with our Portable Wireless Dental X Ray Machine With Mini Digital Sensor For Precision Imaging for a complete mobile dental imaging setup. Affordable and field-ready, this portable dental X-ray machine suits global dental programs of all sizes.
Specific Parameters
| ITEMS | PARAMETERS |
|---|---|
| Imaging Performance | |
| Transmission Power | 140W (70kV, 2mA) |
| Anode Angle | 12.5° |
| Nominal Focal Point | 0.4mm |
| Radiation Tube Lifespan | 60,000+ exposure hours |
| Imaging Quality | High-definition with minimized artifacts and reduced exposure times |
| Control and Interface | |
| Screen Type | 2.8-inch digital touchscreen |
| Interface Controls | Intuitive touch display for exposure time and angle adjustment |
| Sensors | Imported angle sensor with -30° range display |
| Safety Mechanisms | Quick lock screen and automatic risk detection/exposure termination |
| Control System | High-frequency closed-loop import control chip |
| Radiation Safety | |
| Shielding Material | 99.9% high-purity lead sheets |
| Radiation Leakage Rate | Lower than 0.25mGy/h |
| Source-to-Skin Distance | 20cm (focal point to beam-limiting cylinder end face) |
| Protection System | Upgraded system to prevent accidental leakage |
| Power and Battery | |
| Battery Type | Three large-capacity lithium batteries |
| Battery Capacity | 2500mAh each (7500mAh total) |
| Portability | Cordless operation for mobile setups and remote locations |
| Physical Specifications | |
| Motion Range | 360° rotation (horizontal and vertical) |
| Design | Compact, lightweight, and ergonomic for one-handed operation |
| Application Scene | Dental clinics and fast-paced medical environments for all patient types |
Product Details
Feature list for UMY-DE-030
* Compact Handheld Design With 2.5-Inch Digital Touchscreen for Easy One-Hand Use
* 140W at 70kV/2mA High Transmission Output for Fast, Artifact-Reduced Imaging
* Three Independent 2500mAh Lithium Batteries for Extended Cordless Operation
* 60,000+ Hour High-Frequency Radiation Tube for Low Maintenance and Long Service Life
* 99.9% High-Purity Lead Shielding With Auto-Exposure Termination for Operator Safety
Application
Well suited for dental clinics, mobile outreach units, community health programs, and hospital dental departments across global markets. Particularly valuable for facilities seeking a portable, battery-powered dental X-ray alternative to wall-mounted systems. Ideal for procurement teams prioritizing radiation safety compliance, long equipment lifespan, and cordless operational flexibility in diverse clinical environments.
Q1: Can this handheld dental X-ray machine be configured for use with both wired RVG sensors and wireless imaging systems?
A1: The unit supports wired RVG sensor configurations, and wireless sensor compatibility can be confirmed with the sales team based on the clinic’s existing imaging setup.
Q2: How is the device designed to maintain reliable imaging performance and operator safety across high-volume mobile deployment conditions?
A2: The medical-grade housing and internal component mounting are engineered to sustain consistent performance across repeated handling and transport in mobile and field deployment settings.
Q3: What is the standard lead time for international orders and are bundled imaging system configurations available for procurement teams?
A3: Standard lead time is 3 to 7 business days, and procurement teams may also explore the Dental Digital X-Ray Imaging System With APS CMOS Intraoral Sensor For Precise Diagnostics as a complementary solution.
Detail Gallery
