The Digital Mobile-Friendly X-ray Machine is designed for versatile imaging, providing high-quality results for a wide range of medical applications. Its compact, portable design makes it ideal for use in hospitals, emergency care units, and mobile clinics, offering flexibility in patient care. This system ensures clear, detailed images for diagnosing conditions such as fractures, lung diseases, and musculoskeletal disorders. The digital technology allows for faster image acquisition and reduces radiation exposure, improving patient safety and diagnostic efficiency. Perfect for healthcare professionals on the move, it supports effective, accurate diagnostics in various medical settings.
Specific Parameters
| ITEMS | PARAMETERS |
|---|---|
| Power | |
| Extra Power | 5.6kW / 8.0kW |
| Power Source | Support battery-powered and 220VAC |
| Design | Multipurpose, lightweight; ideal for home medical care or emergencies |
| Application Scene | |
| Emergency | Application in emergency situations |
| Indoor Shooting | Suitable for indoor shooting |
| Oversea Voyage | Ideal for use during oversea voyages |
| Touch Screen | |
| Display | Integrated 7-inch capacitive display |
| APR Design | Touch screen APR design, more convenient application |
| Touch Support | Supports MultiTouch |
| Durability | Wearproof, long service life, low maintenance costs |
| Portable Battery (Optional) | |
| Design | Integrated design, small dimension, lightweight, large capacity |
| Performance | Fully charged battery can take 200 images |
| Charging | Supports 110V, 220V charging, convenient and fast |
| Dimensions | 111mm × 188mm × 486mm |
| Technical Specifications | |
| kVp Voltage | 40-125kV (increasing rate 1kV) |
| mAp Current Gears | 5.0, 6.3, 8, 10, 12.5, 16, 20, 25, 32, 40, 50, 63, 80, 100, 125, 160 |
| Exposure Time | 3.2ms-10s; |
| mAs | 0.1-250mAs |
| Working Frequency | 100kHz |
| X-Ray Tube | 0.6mm-1.5mm (40HU 4.0kW) / 0.6mm-2.8mm (76HU 8.0kW) |
| APR | 20 programs |
| Power Source | 220VAC-240VAC / Battery (optional) |
| Physical Specifications | Weight 15kg |
| Dimensions | 230mm × 250mm × 220mm |
| Note | Battery external |
Product Details
- Digital Mobile-Friendly X-Ray Machine: Advanced portable radiography system designed for flexible and efficient medical imaging.
- High-Resolution Digital Imaging: Produces clear, detailed X-ray images for accurate diagnosis and treatment planning.
- Compact and Mobile Design: Easily transported between departments, patient rooms, and healthcare facilities.
- Advanced Digital Radiography Technology: Enables rapid image acquisition and instant image processing for improved workflow.
- Versatile Clinical Applications: Suitable for orthopedic, respiratory, trauma, musculoskeletal, and general radiography examinations.
- Ideal for Bedside Imaging: Supports convenient imaging in intensive care units, inpatient wards, and emergency departments.
- Excellent Fracture Detection: Provides detailed visualization of bones and joints for accurate orthopedic assessments.
- Supports Lung and Chest Examinations: Delivers high-quality thoracic imaging for respiratory disease diagnosis.
- Reduced Radiation Exposure: Optimized digital technology minimizes patient dose while maintaining exceptional image quality.
- Fast Diagnostic Results: Allows immediate image review to support timely clinical decision-making.
- Mobile Healthcare Solution: Perfect for hospitals, clinics, emergency care centers, and mobile medical units.
- User-Friendly Control Interface: Simplifies operation and improves workflow efficiency for healthcare professionals.
- Reliable Emergency Imaging Support: Enables rapid diagnostic evaluations in urgent and critical care situations.
- Stable and Consistent Performance: Designed for dependable daily operation in demanding medical environments.
- Flexible Patient Positioning: Accommodates a variety of examination requirements and patient conditions.
- Digital Image Storage Compatibility: Integrates seamlessly with PACS, RIS, and hospital information systems.
