High-Frequency Portable Handheld Dental X-Ray Machine with 5-Inch Touch Screen
The UMDX012 Portable Dental X-Ray Machine is an advanced oral radiographic diagnostic system that combines exceptional stability with high mobility. Built with a solid-state insulated oil tank, it offers excellent thermal stability and an extremely low ripple rate (< 1%), ensuring stable and reliable X-ray output.
Weighing only 1.8 kg, it is designed for effortless single-handed operation. Equipped with a 5-inch full-color capacitive touch screen, adjustable tube voltage (60–70 kV), and tube current (2.5–3.5 mA), it perfectly adapts to various tooth positions and clinical imaging requirements.
Key Features
1.8 kg Ultra-Lightweight Design
Compact and lightweight housing significantly reduces single-handed operation fatigue during high-frequency daily examinations.
5-Inch Capacitive Touch Screen
Intuitive graphical user interface enables quick parameter adjustment and exposure status preview.
Flexible Adjustable Output
Tube voltage (60 kV – 70 kV) and tube current (2.5 mA, 3.5 mA) can be adjusted to easily handle various adult and pediatric dental exposures.
Four-Layer Radiation Safety Protection
Built-in multi-layer radiation shielding structure effectively blocks scatter radiation, ensuring operator and patient safety.
Solid-State Insulated Oil Tank Technology
Proprietary high-frequency oil tank design delivers stable output, low ripple (< 1%), and extended operational life.
High-Frequency Inverter
Inverter frequency exceeds 100 kHz with precise exposure timing (0.01 – 1 second), effectively minimizing motion blur.
Technical Specifications
| Specification Item | Technical Parameter |
|---|---|
| Product Model | UMDX012 (RV-210RH) |
| Tube Voltage | 60 kV to 70 kV Adjustable |
| Tube Current | 2.5 mA, 3.5 mA Adjustable |
| High-Voltage Ripple Frequency | < 1% |
| Inverting Frequency | > 100 kHz |
| Display Screen | 5-inch Capacitive Touch Screen |
| Exposure Time Range | 0.01 – 1.00 Seconds |
| Exposure Time Step | R20 Coefficient |
| Radiation Protection | Four-Layer Radiation Leakage Protection |
| Net Weight | 1.8 kg |
| Dimensions | 190 mm × 126 mm × 145 mm |
- Specifications are based on the official technical documentation of the UMDX012 portable X-ray unit.
- Recommended to be used in combination with digital intraoral sensors (RVG) or imaging plates (IP) for optimal imaging results.
Applications
Dental Clinics & Operatories
Ideal for routine chairside periapical radiographs, orthodontic diagnostics, and pre-implant assessments.
Mobile Medical & Bedside Diagnostics
Perfect for mobile dental vans, nursing home visits, and bedside radiography for mobility-impaired patients.
Veterinary Dental Care
Suitable for small animal dental radiography and routine clinical checkups.
Before Ordering
To ensure proper system compatibility and provide an accurate export quotation, please provide:
- Required order quantity and destination country.
- Whether compatible digital dental sensors (RVG) or image plate scanners are required.
- Local medical device registration or radiation safety compliance requirements.
Request a UMDX012 Portable X-Ray Quote
Contact UMY Medical to discuss volume pricing, lead times, and export shipping solutions for your equipment project.
Please include your destination country and required quantity so our sales team can assist you promptly.
Frequently Asked Questions
How heavy is the UMDX012 portable X-ray machine?
The unit features an ultra-lightweight design weighing only 1.8 kg, making single-handed holding easy and effortless.
What kind of screen does it use for control?
It is equipped with a 5-inch capacitive touch screen offering an intuitive interface for quick parameter adjustments.
Are tube voltage and current adjustable?
Yes, it supports tube voltage adjustments from 60 kV to 70 kV and tube current settings of 2.5 mA and 3.5 mA.
