Vetus 5s Vet Diagnostic Ultrasound System for Routine and Specialized Imaging
SKU: UMY-US-120
Brand: Umy
MOQ: 1
Origin: China
Quick Info.
- SKU NO.: UMY-US-120
- Device Classification: Class Ⅱ
- Warranty: 1 Year
- Power Source: Electric
- Transport Package: Carton or Wooden Box
- Origin: China
- Material: Metal, Plastic
- After-Sale Service: Online Technical Support
- Production Capacity: 3000 Sets/Year
The Vetus 5s Veterinary Ultrasound System combines precision imaging with user-friendly design, supporting routine exams and specialized diagnostics in various animal species. With advanced imaging features such as color Doppler, compound imaging, and elastography, it delivers high-definition visuals for accurate assessment of abdominal, reproductive, and cardiac conditions. The system is optimized for daily clinical use, offering efficiency, reliability, and flexibility for general practice and referral hospitals. Multiple transducer options further expand its clinical versatility across small and large animals.
The Specific Parameters
| ITEMS | PARAMETERS |
|---|---|
| Key Features | |
| Monitor Size | 54.6 cm high-resolution LED monitor |
| Touch Screen Size | 33.7 cm anti-glare touch screen |
| Design Features | Easy cleaning and disinfection surfaces |
| Transducer Ports | 4 active transducer ports |
| Wheels | Anti-hair-wrapped wheels with 360° rotation |
| Wi-Fi Connectivity | 300 Mbps Wi-Fi for easy connection |
| Keypad | Sliding keypad with anti-liquid, anti-animal hair silicon film |
| Speciality Features | |
| Needle Guidance | iNeedle for biopsy needle enhancement |
| Imaging | Elastography Imaging |
| Volume Calculation | Smart Bladder for automatic volume calculation |
| Tissue Doppler Imaging | Supports modes TVI, TVD, TVM, TEI and TDI QA |
| Animal Abdomen Solutions | |
| Imaging | iScape real-time panoramic imaging |
| Needle Guidance | iNeedle for biopsy needle enhancement |
| Imaging | Elastography Imaging |
| Contrast Imaging | UWN Contrast Imaging |
| Volume Calculation | Smart Bladder for automatic volume calculation |
| Animal Cardiac Solutions | |
| Tracking & Analysis | CW/PW automatic tracking & analysis |
| M Mode | Free Xros M for anatomical M mode |
| Curved M Mode | Free Xros CM for curved anatomical M mode |
| Tissue Doppler Imaging | Supports 4 modes |
| Quantitative Analysis | Tissue Doppler Imaging with Quantitative Analysis |
| Key Features (Additional) | |
| Monitor Size | 21.5” high definition LED monitor, 180-degree rotation |
| Touch Screen Size | 13.3” anti-glare touch screen, 30-degree rotation, multi gesture support |
| Monitor Arm | Dual-Wing floating monitor supporting arm |
| Control Panel | Anti-dirty control panel, rotatable & height adjustable |
| Keyboard | Sliding keyboard with designed silicon cover |
| Transducer Sockets | 4 active smart transducer sockets with easy lock design |
| Battery | High capacity battery for standby mode |
| Cable Management | Transducer cable management to keep cables off the ground |
| Wheels | Stable wheels with small footprint, 360° rotation |
| Transducers | |
| C11-3s | Classical Micro convex array transducer for abdomen, Extended FOV: 140° |
| L12-3E | High frequency linear array for multi-sized animal |
| C6-2 | Convex array for large-sized animal |
| L14-6 | High frequency linear array for small-sized animal |
| P8-2 | Mid/high-frequency phased array for mid and small-sized species |
| P10-4E | High-frequency phased array for small-sized species |
| P4-2 | Low-frequency phased array for large species |
| Application Areas | |
| Abdomen & Reproduction | C11-3 Micro convex array for small-sized animal |
| Large Animal Imaging | C6-2 Convex array for large-sized animal |
| Superficial & Musculoskeletal | L12-3E High frequency linear array for multi-sized animal |
| Small Animal Imaging | L14-6 High frequency linear array for small-sized animal |
| Cardiology | P8-2 Mid/high-frequency phased array for mid and small-sized species |
| Cardiology | P10-4E High-frequency phased array for small-sized species |
| Cardiology | P4-2 Low-frequency phased array for large species |
