Handheld X-Ray Unit for Human & Vet Clinical Imaging OEM Available
Quick Info.
- SKU NO.: UMY-XM-082
- Device Classification: Class Ⅱ
- Warranty: 1 Year
- Power Source: Electric
- Transport Package: Carton or Wooden Cases
- Origin: China
- Material: Aluminum & Magnesium Alloys and Plastic
- After-Sale Service: Online Technical Support
- Production Capacity: 2900 Sets/Year
The UMY-XM-082 portable handheld X ray unit provides high quality diagnostic imaging with a compact 1.6 kg design and output power of 360W. It operates at 100 kHz frequency with a kV range of 40 to 70 kV and supports 0.01 to 10 mAs exposure, making it suitable for mobile clinics, dental practices, and field diagnostics. The device features both button and remote control operation for user convenience. Its lightweight build ensures easy transport while maintaining reliable performance in diverse medical environments.
For additional imaging capabilities, healthcare providers can also explore the Color Doppler Ultrasound Machine with 21.5 inch Medical LCD Monitor and Articulating Arm.
The Specific Parameters
| ITEMS | PARAMETERS |
|---|---|
| Technical Specifications | |
| kV Range | 40 ~ 70kV |
| mA Range | 1 ~ 8mA |
| Exposure Time (S) | 0.01 ~ 4.0s |
| mAs Range | 0.01 ~ 10mAs |
| Exposure Mode | Button, remote control |
| Weight | 1.6kg |
| Power | 360W |
| Power Adapter Input | 110 ~ 220VAC ±10%, 50/60Hz |
| Operating Frequency | 100kHz |
Feature list for UMY-XM-082
* Precise kV and mA control for versatile imaging
* User-friendly operation with remote control
* High-voltage generator with tube calibration for accurate results
* Compact and efficient design for easy installation
Application
Ideal for veterinary clinics, small animal practices, and diagnostic centers requiring accurate X-ray imaging for a wide range of animals, from pets to larger livestock.
