Flexible Vet Fiber Endoscope Video Pharyngoscope for Dogs Cats Horses and Cattle
Quick Info.
Power Source: Electric
Warranty: 1 year
After-sale Service: Online service and delivering spare parts
Transport Package: Carton or Wooden Cases
Material: Metal, Plastic
Instrument Classification: Class Ⅱ
Quality System Standard: ISO13485
- SKU NO.: UMY-VEEN-015
- Warranty: 1 Year
- Origin: China
The veterinary fiber flexible endoscope is engineered for comprehensive airway and gastrointestinal examinations in small and large animals. Available in four tube sizes from 8.0 mm to 14 mm with working lengths up to 3000 mm, it adapts to species from cats and dogs to horses and cattle. Its CMOS imaging system ensures clarity for detecting esophageal strictures, laryngeal paralysis, tumors, and foreign body obstructions. The bending range of up to 210° supports maneuverability in complex anatomical regions. LCD monitors of 3.5 or 5 inches provide real time visualization while working channels allow biopsy and treatment. For additional diagnostic support, clinics can explore the Cost-Effective Portable Veterinary Ultrasound Scanner for Animal Pregnancy Detection.
The Specific Parameters
| ITEMS | PARAMETERS |
|---|---|
| Φ8.0mm Insertion Tube | |
| Outer Diameter | Φ8.0mm |
| Depth of View | 3–100 mm |
| Bending Range | Up 210°, Down 90°, L/R 100° |
| Working Channel | Φ2.0 mm |
| Working Length | 1500 mm |
| LCD | 5.0″ |
| Resolution | CMOS 160000 pixels |
| Φ9.8mm Insertion Tube | |
| Outer Diameter | Φ9.8mm |
| Depth of View | 3–100 mm |
| Bending Range | Up 210°, Down 90°, L/R 100° |
| Working Channel | Φ2.8 mm |
| Working Length | 2000 mm |
| LCD | 5.0″ |
| Resolution | CMOS 160000 pixels |
| Φ12.8mm Insertion Tube | |
| Outer Diameter | Φ12.8mm |
| Depth of View | 3–100 mm |
| Bending Range | Up 210°, Down 90°, L/R 100° |
| Working Channel | Φ3.2 mm |
| Working Length | 3000 mm |
| LCD | 3.5″/5.0″ |
| Resolution | CMOS 160000 pixels |
| Φ14.0mm Insertion Tube | |
| Outer Diameter | Φ14.0mm |
| Depth of View | 3–100 mm |
| Bending Range | Up 216.3°, unspecified downward and L/R range |
| Working Channel | Not specified |
| Working Length | 3000 mm |
| LCD | 5.0″ |
| Resolution | CMOS 160000 pixels |
Feature list for UMY-VEEN-015
* CMOS resolution of 160,000 pixels
* Multiple outer diameters for flexible use
* Bending range of 210° (upward) and 90° (downward)
* Ergonomically designed for ease of handling
* Ideal for detailed ENT examinations and diagnostics
Application
Ideal for ENT clinics, emergency rooms, and specialized medical centers, this rhino-pharyngoscope provides high-quality imaging for the diagnosis and management of nasal and pharyngeal conditions in both adults and children.
